Da Ros Seeder LR400

Overview

Integrated electronic seeder holding drum system and row by row system. It allows high production working as well as many small stocks of difficult seeds. The drum seeder has different speed control of the drum and transport belt allowing to deposit more seeds per cell without changing the drum. The row by row system allows to make use of a small quantity of seeds (naked or pelleted). The seeder dibbles, sows, covers (with Vermiculite/Agriperlite), waters and stacks. The adjustment of these operations and the speed of the belt are controlled from the touch screen control panel.

The easy adjustment and the simplicity in changing the drums, seeding bars and/or nozzles, allows to seed in different types of trays with different types of seeds. The machine can be fed by a trayfiller without making electrical connections.

MACHINE COMPOSITION • Support frame • Tray advancement belt • Flat dibbling unit • Drum unit • Bar unit • Sub-silent vacuum pump • Drum covering group • Watering group • Tray stacker

ACCESSORIES • Kit (drum) mod. LRK • Kit (bar) mod. BFL • Nozzles mod. UG • Belt covering group (sand or peat) mod. GRTS • Automatic unloading system of stacks on rolling table mod. SSP • End rolling table mod. RS

TECHNICAL DATA:

• Production Capacity: 50 to 400 trays per hour
• Maximum Trays Size: 600x400x130 mm
• Installed Power: 1.2 kW, 400 V, 3PH+N+E, 50 Hz
• Air Consumption: 50 to 150 L per minute
